Sailing

HR Snap Shackle Webbing Swivel - 100mm Length - 3-15/16"Features: HR Forged snap shackle (Grade 17.4 PH stainless steel) with webbing swivel. Its flat design allows attaching a webbing Free rotation of the snap shackle thanks to the swivel eye The plunger pin is set captive into the hook and cannot become detached Excellent working and breaking loads Easy to open by pulling the plunger pin (possible to attach a lanyard) Applications: Snap shackle applications Applications requiring a free rotation of the snap shackle (for a better sail orientation) Specifications: Materials: HR 17.4 PH stainless steel grade Working load: (lb) 2820 / (kg) 1280  Breaking load: (lb) 8480 / (kg) 3850  Dimensions: A: (inch) 53/64" / (mm) 21  B: (inch) 1 37/64" / (mm) 40  Length: (inch) 3 15/16" / (mm) 100  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load.  WLL = Breaking load / 5 High Resistance (HR) *Sold as an Individual Quick Guide (pdf)

Read more less

DO 550 Rope Clutch - Handle Replacement handle for any size Barton Marine DO 550 Rope Clutch.*Sold as an Individual Specifications: Color: Black Box Dimensions: 2"H x 3"W x 6"L WT: 0.1 lbs UPC: 5035088815456 Brochure (pdf)

Read more less

DO 550 Rope Clutch - Spring Assembly   Replacement spring assembly for any size Barton Marine DO 550 Rope Clutch.*Sold as an Individual Specifications: Color: Silver Box Dimensions: 1"H x 4"W x 6"L WT: 0.01 lbs UPC: 5035088815494 Brochure (pdf)

Read more less

57mm Aluminum Low Load Black Magic Block with SwivelBlack Magic Air blocks are a top favorite of Big Boat performance racers and cruisers. These lightweight, free-running, powerful performers are used for sail controls that see lots of action: mainsheet, runner, halyard, and spinnaker systems. A center cage keeps Torlon® roller bearings separated and parallel to reduce friction. Shackle blocks lock in two directions or swivel to keep the line from twisting. Low-load blocks have red isolators. They use Torlon® rollers and 316 stainless steel shackles. Standard blocks have 17-4 PH stainless head posts. Torlon is a registered trademark of Solvay Advanced Polymers L.L.C. Specifications: Sheave: 57mm/2-1/4in Length: 119mm/4-11/16in Weight: 154g/5.44oz Shackle Pin: 6mm/1/4in Maximum Line: 12mm / 7/16in Maximum Working Load: 7/16kg / 1655lbs Breaking Load: 1500kg / 3300lb

Read more less

35 Self-Tailing Radial Aluminum Winch - 2 SpeedThe Radial winch drum’s gripping surface is shaped for each winch size and drum material and features diagonal ribs (rather than textured abrasive materials) to maximize gripping power and greatly reduce line wear. The self-tailing mechanism on the winch means that one crew member can quickly and easily trim or raise sails.Specifications: Material: Aluminum Configuration: Self-tailing Speed: 2 Drum: 80mm/ 3-1/8in Base: 149 mm/ 5-7/8in Height: 170mm/ 6-11/16in Weight: 3.6kg/ 7.9lb Line entry height: 79mm/ 3-1/8in Minimum line: 8mm/ 5/16in Maximum line: 12mm/1/2in Fastener circle: 123mm/ 4-7/8in Fasteners: 6 SH mm/ 1/4 SH in Number of fasteners: 5 Gear ratio-1: 2.13 Gear ratio-2: 5.65 Power ratio-1: 13.50 Power ration-2: 35.90 Available power: Manual

Read more less

2-3/4" Snap Shackle with Fixed Eye - 70mmFeatures: HR Forged snap shackle (Grade 17.4 ph stainless steel) with fixed eye The plunger pin is set captive into the hook and cannot become detached Excellent working and breaking loads Easy to open by pulling the plunger pin (possibility to attach a lanyard) Applications: Snap shackle applications with fixed eye Use for applications where the free rotation is not required

Read more less

1-3/8" Snap Shackle with Fixed Eye - 35mmFeatures: Forged snap shackle (316L) with fixed eye The plunger pin is set captive into the hook and cannot become detached Excellent working and breaking loads Easy to open by pulling the plunger pin (possibility to attach a lanyard) Applications: Snap shackle applications with fixed eye Use for applications where the free rotation is not required

Read more less

Symmetric Carbine Hook - Length 60mm - 1/4"Features: Grade 316L stainless steel carbine hooks Symmetrical shape With eye to attach a webbing or a splicing Applications:For fastening applications Specifications: Materials 316L stainless steel grade Length (inch) 2-23/64" Working load (lb) 790 WLL (lb) 260 Breaking load (lb) 1320 Weight (lb) 0.066 Dimensions (see 2nd image): A (inch) 25/64" B (inch) 9/32" D diameter (inch) 15/64"

Read more less

Asymmetric Carbine Hook - Length 170mm - 15/32"Features: Grade 316L stainless steel carbine hooks Asymmetrical shape to support higher loads With eye to attach a webbing Applications: For fastening applications Integrated on Wichard tether Specifications: Materials 316L stainless steel grade Length (inch) 6-11/16" Working load (lb) 3170 WLL (lb) 1980 Breaking load (lb) 9920 Weight (lb) 0.741 Dimensions (see 2nd image): A (inch) 1-3/16" B (inch) 25/32" D diameter (inch) 15/32"

Read more less

57mm Carbo Block Flip Flop with CamSmall Boat Flip-Flop blocks pivot around the line axis to keep the line close to the deck. Hinged construction allows for various lead angles.Features: Sheave Ø (mm) 57 mm Sheave Ø (in) 2 1/4 in Maximum line Ø (mm) 10 mm Maximum line Ø (in) 3/8 in Maximum working load (kg) 136 kg Maximum working load (lb) 300 lb

Read more less

Sticky Race Gloves - Black - XSFeatures: Synthetic leather for maximum durability, minimum stretch and shrinkage  Double aramid stitched in high wear areas  Double thickness palm and fingers for protection and grip  Hook-and-loop wrist closure/adjustment  Low cut wrist band for free movement and ClearStart™ watch visibility and operation  Mesh panels for flexibility and comfort Applications:Used for hand protection and grip Brochure (pdf)

Read more less

Sticky Race Gloves - 3-Finger - Black - XSFeatures: Synthetic leather for maximum durability, minimum stretch and shrinkage Double aramid stitched in high wear areas Double thickness palm and fingers for protection and grip Hook-and-loop wrist closure/adjustment Low cut wrist band for free movement and ClearStart™ watch visibility and operation Mesh panels for flexibility and comfort Mesh panels for flexibility, comfort and quick drying - now available in Grey Sticky gloves reduce fatigue by minimising the physical effort required to hold rope Applications:Used for hand protection and gripMaterials: 'Amara’ synthetic leather Double Aramid stitching Brochure (pdf)

Read more less
