38mm Single Big Bullet Block with BecketLow-friction Bullet blocks lead control lines aft. They are compact and lightweight, with fast trim and release under high or low loads. A range of styles lets these blocks adapt to almost all control line applications. Features: Sheave: 38mm (1-1/2") Maximum Line: 10mm (3/8") Maximum Working Load: 136kg (300lb)

Read more less

14mm Lead RingLead Rings are simple, weight-saving devices used to route line for jib in-haulers, twings, barberhaulers, lazy jacks, cascading backstays and other applications requiring minimal fine-tune adjustments. Rings are Hard Lube-anodized 6061-T6 aluminum for a smooth, slippery surface, and with no moving parts, wear is minimal.Features: Center Hole: 14mm (9/16") Outer groove width: 10mm (7/16")

Read more less

16mm Double Block with Becket The 16 mm is Harken’s® smallest block. It is perfect for small synthetic control lines found on high-tech dinghies. The patented bearing system uses stainless steel balls in a captive grooved race.Specifications: Sheave: 16mm / 5/8in Length: 54mm / 2-1/8in Weight: 28g / 1oz Maximum line: 5mm / 7/32in Maximum working load: 204kg/ 450lb Breaking load: 544kg / 1200lb

Read more less

Open Body Turnbuckle with Splice Eye*Dyneema Line not included with fittingsC. Sherman Johnson Marine's Splice Line fittings allow you to easily splice hi tech Dyneema line to standard life line fittings. The Splice Line fittings are designed to be light weight and easy on the line. Both US Sailing and ISAF now allow Dyneema/ Spectra life lines for offshore racing and Dyneema/ Spectra is also a great product for the cruising sailor that wants to replace their stainless steel life line cables. Professional splicing recommended.

Read more less

12 ST FS Self-Tailing Manual Single Speed Winch - Full StainlessPower Rib™ANDERSEN Winches feature the Power Rib™. Unlike other winches with abrasive drum surfaces, ANDERSEN winch drums have vertical ribs running up the surface. This combined with the smooth polished stainless steel gives a maximum grip and minimum wear on ropes, reducing the replacements costs of sheets and halyards. What’s more, the Power Rib principle simply makes sailing more pleasurable. Fewer turns on the winch make tacking easier. Sheets can be gently eased out without harsh snatching and the risks of overrides and jammed sheets are significantly reduced. The grip provided by the ribs will remain the same year after year, unlike many other winches with an abrasive or sandpaper-like surface. Such surfaces have a tendency to wear down both ropes and themselves.Power RatioPower Ratio is the mechanical advantage of the winch and is calculated as follows:length of handle x gear ratio           radius of drumThe pull of the winch is based on the Power Ratio and not just on the physical size of the winch or the diameter of the drum. The Power Ratio is used to determine the load the winch may handle as follows: pull of handle (kg x Power Ratio = pull of winch (kg).This means that by applying a load of 10kg, using a 10" standard handle, on a Power Ratio 40:1 winch, the winch can pull 400kg, assuming that the winch is 100% efficient. This is not possible in practice as the efficiency is reduced by internal mechanical friction losses.Specifications: Drum Ø D: 2-3/4" Base Ø B: 4-1/2" Height H: 5" Line Entry L: 1-3/4" Line Size: 5/16-9/16" Weight: 5.7lb Gear ratio 1st speed: 1.3 : 1 Power ratio 1st speed: 9.5 :1 Quick Guide (pdf)

Read more less

Size 2 Single Swivel BlockA strong, lightweight range of blocks for use on dinghies and dayboats or as lead blocks on larger craft. Size 2 - Single Swivel Block.

Read more less

Large Wincher PairThe Barton Wincher is a specially designed rubber molding that converts your standard winch into a self-tailing winch.  This tried and tested design has been a firm favorite with Sailors for many years.The Wincher works by gripping the rope when the drum is fully loaded and under tension, peeling off the line from the underside of the Wincher as you winch to give a true self-tailing motion.Cleating is achieved by locking the sheet into the Wincher’s ribbed central groove.Technical Specifications: Fits Drum Diameter - 3" to 3.5" (76.2 to 88.9 mm) Maximum Rope Diameter - .47" to .55" (12 to 14 mm) Weight - 9.8 oz (278 g)  *Sold as a Pair Brochure (pdf)

Read more less

Extra Large Wincher PairThe Barton Wincher is a specially designed rubber molding that converts your standard winch into a self-tailing winch.  This tried and tested design has been a firm favorite with Sailors for many years.The Wincher works by gripping the rope when the drum is fully loaded and under tension, peeling off the line from the underside of the Wincher as you winch to give a true self-tailing motion.Cleating is achieved by locking the sheet into the Wincher’s ribbed central groove.Technical Specifications: Fits Drum Diameter - 3.5" to 4" (90 to 100 mm) Maximum Rope Diameter - .47" to .63" (12 to 16 mm) Weight - 13.65 oz (387 g)  *Sold as a Pair Brochure (pdf)

Read more less

Size 7 Single Plain Bearing Stand-Up BlockBarton plain bearing blocks have a precision molded acetal sheave running on a large diameter brass bearing, ensuring free running under the highest of loads. This range of high-load cruiser bocks is of rugged construction, featuring high-quality injection molded side plates with all load-carrying components from 316-grade stainless steel. Side plates are through-bolted and riveted for added strength and security.Features:This good-looking and versatile range is designed for use on larger cruising and racing yachtsSpecifications & Dimensions: Length: (mm) 162 / (inch) 6-3/8" Weight (grams): 444 g. Single (mm) 70 x 20 / (inch) 2-3/4" x 3/4" Max Rope Diameter: (mm) 14 / (inch) 9/16" SWL: (kg) 1250 / (lbs.) 2750 Break Load: (kg) 2500 / (lbs.) 5500 Note: break loads where break and safe working loads are stated, it is assumed that all sheaves are evenly loaded as in a purchase tackle Uneven loading, or loading of one sheave in a double or triple block, will severely affect the strength quoted.

Read more less

SkyDock Storage System 4 to 1 Reduction Up to 175 LBS 4-Point LiftSkyDock is the ultimate roof space storage solution for loads up to 175 lbs (80 KG.)  Designed for use in any space with a ceiling height up to 13' (4 M), the SkyDock works in garages, sheds, barns, and lofts for commercial uses in yards, marinas, yacht clubs and warehouses.Utilizing a 4:1 purchase system,  It smoothly lifts bulky and awkward objects or loads, out of the way, from the floor or roof of your car, to stow them up high until needed again.  Ideal for dinghies, kayaks, canoes, paddleboards, camping equipment, roof boxes, bicycles, garden furniture, horse saddles, pallets of assorted bits and pieces, and any kit that needs to be stored out of the way, but retrieved easily and smoothly when needed.Designed with a unique self-locking block, meaning loads can be raised by one person without stress.  If the control line is released the locking block firmly holds the load, stopping items from falling.  For ultimate security, a fixed wall cleat is supplied to tie off the line.Features: Complete garage storage solution for dinghies, kayaks, canoes, camping equipment, etc Easily raised by one person Self-locking cleating block Comprehensive fitting instructions provided Technical Specifications: Mechanical Advantage - 4:1 Maximum Lift Capacity -  175 lbs (80 KG) Maximum Lif Height - 13' (4 M), In the Box: 1 x Black control line with SkyLock block and fiddle block for 4:1 mechanical advantage  5 x Eye bolts 4 x Pulley blocks with shackles 1 x Blue lifting line 2 x Blue lifting straps 1 x Rope organizer with 2 bolts 1 x Horn cleat with 2 screws 1 x Instruction manual *Sold as an Individual Kit Brochure (pdf)

Read more less

Genoa Slide with Loop for 32mm TrackHave a heavy-duty stainless steel attachment loop, through-bolted and riveted for extra strength. These units will accept most Barton blocks. A popular range of Genoa cars and sliders designed to run on a 32mm (11/4") 'T' track. All are manufactured from high-quality marine grade aluminum and finished with our unique 'Spectro' grey anodized finish for added protection. This slider has molded nylon inserts to ensure free, smooth running under load and prevent damage to the finish or potential corrosion. Features: 'Spectro' grey anodized finish The stainless steel plunger stops with positive action Molded nylon slide inserts ensure free running Large, easy-grip plunger knobs Heavy-duty Genoa car options 32mm 'T' section trackDrilled for fastenings and plunger stops. 'Spectro' grey anodized and supplied in metric lengthsSpecifications & Dimensions: Length: (mm) 109 / (inch) 4-5/16" Width: (mm) 52 / (inch) 2-1/16" Height: (mm) 50 / (inch) 1-15/16" Break Load: (kg) 2980 / (lbs.) 6,570 SWL: (kg) 1490 / (lbs.) 3,285  Weight (grams): 254 g Quick Guide (pdf)

Read more less

SkyDock Storage System 3 to 1 Reduction Up to 175 LBS 4-Point LiftSkyDock is the ultimate roof space storage solution for loads up to 175 lbs (80 KG.)  Designed for use in any space with a ceiling height of up to 13' (4 M), the SkyDock works in garages, sheds, barns, and lofts for commercial uses in yards, marinas, yacht clubs, and warehouses.Utilizing a 3:1 purchase system,  It smoothly lifts bulky and awkward objects or loads, out of the way, from the floor or roof of your car, to stow them up high until needed again.  Ideal for dinghies, kayaks, canoes, paddleboards, camping equipment, roof boxes, bicycles, garden furniture, horse saddles, pallets of assorted bits and pieces, and any kit that needs to be stored out of the way, but retrieved easily and smoothly when needed.Designed with a unique self-locking block, meaning loads can be raised by one person without stress.  If the control line is released the locking block firmly holds the load, stopping items from falling.  For ultimate security, a fixed wall cleat is supplied to tie off the line.Features: Complete garage storage solution for dinghies, kayaks, canoes, camping equipment, etc Easily raised by one person Self-locking cleating block Comprehensive fitting instructions provided Technical Specifications: Mechanical Advantage - 3:1 Maximum Lift Capacity -  175 lbs (80 KG) Maximum Lif Height - 13' (4 M), In the Box: 1 x Black control line with SkyLock block and pulley block for 3:1 mechanical advantage 5 x Eye bolts 4 x Pulley blocks with shackles 1 x Blue lifting line 2 x Blue lifting straps 1 x Rope organiser with 2 bolts 1 x Horn cleat with 2 screws 1 x Instruction manual  *Sold as an Individual Kit Brochure (pdf)
