• Lewmar Windlass Thermal Circuit Breaker Panel - 70Amp [68000240]
1 1

Lewmar Windlass Thermal Circuit Breaker Panel - 70Amp [68000240]

$123.89
$182.95
$123.89
Shipping calculated at checkout.

SKU: CWR-94341   UPC:

[COUNT] shoppers are looking at this right now

    Windlass Thermal Circuit Breaker Panel - 70Amp

    Panel mounted, a waterproof breaker that works with DC systems up to 48 volts.  This trip-free breaker is ideal for a windlass circuit.

    Features:

    • Works with DC systems up to 48 volts
    • Clear, single lever operation
    • Combines switching and circuit protection into a single device
    • "Trip Free" design cannot be held "ON" during fault current condition
    • Ignition protected

    Technical Specifications:

    • Circuit Breaker Class - Type III
    • Circuit Breaker Type - Thermally responsive bi-metal blade
    • Maximum Voltage - 48V DC
    • Amperage - 70Amp
    • Mounting - Panel Mount
    • Weight: -.5lb (0.23 kg)

    *Sold as an Individual

    Specifications:

    • Amperage: 100a
    • Box Dimensions: 1"H x 4"W x 5"L WT: 0.4 lbs
