Blue Sea 7615 ATD Automatic Timer Disconnect [7615]

$148.89
$164.99
$148.89
Shipping calculated at checkout.

SKU: CWR-64363   UPC: 632085076153

[COUNT] shoppers are looking at this right now

    ATD Automatic Timer Disconnect

    Adjustable time or voltage based battery disconnect automatically shuts off devices to preserve battery power

    • 12V signal triggers relay to connect battery power to devices. When signal is removed the timer is activated and will disconnect devices after a preset time
    • Disconnect can be triggered based on time, low voltage, or removal of 12V signal
    • Low voltage will disconnect if time hasn_t been reached to preserve battery power
    • Time and voltage options can be turned off to allow 12V signal based disconnect
    • Clip-on cover insulates terminal connections
    • One-piece stainless flange nuts ensure safe and secure connections
    • Integrated LED indicates status


    Specifications:
    • Nominal Voltage:12V DC
    • Amperage Operating Current: 175mA(Combine / 15mA(Open)
    • Continuous Rating:120A
    • Intermittent Duty: 210
    • Terminal Stud Size: 3/8"-16 (M10)
    • Time Range: 15min-4hrs

    WarningWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.


    Owner's Manual (pdf)
