• Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof [206-051S]
1 1

Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof [206-051S]

$27.26
$34.95
$27.26
Shipping calculated at checkout.

SKU: CWR-29828   UPC: 602290201404

[COUNT] shoppers are looking at this right now

    Panel Seal/Waterproof "A" Frame Magnetic Circuit Breakers


    • Branch AC or DC circuit breaker for Paneltronics electrical distribution panels
    • Meets all American Boat and Yacht Council (ABYC) Standards for non-ignition protected circuit breakers
    • UL Recognized (UL 1077) for use in th USA, and CSA Certified for use in Canada
    • Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)
    • Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1)
    • Handle Color - Metal with silicon rubber seal
    • Maximum Aperage - 50 Amps
    • Maximum Voltage/AIC - 32 VDC/2,500 amps with no back-up fuse (ABYC E-11.10.1.5.5)
    • Rated Switch Cycles - 10,000 actuations at rated current and voltage
    • Electrical Hardware - Hex nut 1/2-32 (supplied with circuit breaker); Lockwasher 1/2" internal tooth (supplied with circuit breaker)
    • Optional Boot - Black silicone rubber (P/N 048-015)

      Specifications:

      • Color: Stainless
      • Throw/Pole: SPST
      • Box Dimensions: 2"H x 2"W x 2"L WT: 0.2 lbs
      • UPC: 602290201404
