4mm Shallow Bow ShackleForged stainless steel shackles are polished to a high luster and are stamped with the screw pin diameter.Bow shackles are best for multidirectional loads. Shallow bow shackles are proportionally wider for their length than regular bow shackles.Specifications: Shackle pin: 4mm / 5/32in Weight: 8.5g / 0.3oz Maximum working load: 367kg / 810lb Breaking load: 735kg / 1620lb

Read more less

40mm Carbo Air Pivoting Lead Block with Aluminum Cam-Matic® CleatHigh-strength pivoting lead blocks with cams are used for halyard controls on larger keelboats and as “headknockers” on dinghies and beachcats for sheeting directly from the boom. Hole spacing and rivet size are the same as Classic models, making upgrades easy. Cam reverses for either up or down cleating.Can be used as becket block.Specifications: Sheave Ø (mm)40 mm Sheave Ø (in)1 9/16 in Maximum line Ø (mm)10 mm Maximum line Ø (in)3/8 in Maximum working load (kg)136 kg Maximum working load (lb)300 lb

Read more less

16mm Block with SwivelThe 16 mm is Harken’s® smallest block. It is perfect for small synthetic control lines found on high-tech dinghies. The patented bearing system uses stainless steel balls in a captive grooved race and has a 250 lb (113 kg) maximum working load.Specifications: Sheave: 16mm / 5/8in. Length: 46mm / 1-13/16in. Weight: 18g / .63oz Shackle pin: 4mm / 5/32in Maximum line: 5mm / 7/32 Maximum working load: 113kg/ 250lb Breaking load: 339kg / 750lb

Read more less

Opening Luff Rope PrefeederFeatures: Single-handed operation by pushing on the spring Easy to install with a lashing or fixed to the forestay Can be installed below any headsail foil or headsail reefing configuration Stainless steel forged part Applications: Ideal for bowman operations No need to remove the headsail from the luff grove Enables to save time during operations Smooth and easy sail hoist Specifications: Materials 316 stainless steel grade Weight (lb) 0.11

Read more less

HR Snap Shackle - Large Bail - Length 80mmFeatures: HR Forged snap shackle (Grade 17.4 PH stainless steel)  with large eye The large eye allows attaching several ropes Free rotation of the snap shackle thanks to the swivel eye The plunger pin is set captive into the hook and cannot become detached Excellent working and breaking loads Easy to open by pulling the plunger pin (possibility to attach a lanyard) Applications: Snap shackle applications Applications requiring a free rotation of the snap shackle (for a better sail orientation) Specifications: Materials HR 17.4 PH stainless steel grade Length (inch) 3-5/32" Working load (lb) 2110 Breaking load (lb) 4400 Weight (lb) 0.154 Dimensions (see 2nd image): A (inch) 5/8" B (inch) 3/4"

Read more less

Captive Pin D Shackle - Diameter 8mm - 5/16"Features: Captive pin "D" shackle forged in grade 316L stainless steel The pin is connected to the body at all times even when opened The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads Applications: Standard applications of shackle Attachment applications: blocks, head... Specifications: Materials 316 stainless steel grade Working load (lb) 2200 WLL (lb) 1580 Breaking load (lb) 7930 Weight (lb) 0.134 Dimensions (see 2nd image): A (inch) 1-1/32" B (inch) 5/8" C (inch) 23/64" D (inch) 45/64" D diameter (inch) 5/16" E (inch) 5/16" F (inch) 1-27/32" G (inch) 1-21/32"

Read more less

Series 7 Flat Base/Aluminum Cheek/Delrin SheaveDelrin™ sheave ensures smooth operation and high safe working load. Stainless steel base distributes loads to a large surface area. Specifications: Sheave Dia. 2-3/8" (60 mm) Max. Line 1/2" (13 mm) Length 4-3/8" (111 mm) Width  2-3/4" (70 mm) Height 1" (25 mm) Fasteners (4) 1/4" RH (6 mm) C/C 3-5/8" (92 mm) C/C (wide end) 2" (51mm) C/C (narrow end) 1-9/16" SWL 2250 lbs. (1020 kg) Weight Alum. 9.6 oz. (272 g)

Read more less

Winch Handle PocketMountable anywhere in a vertical position and fits 10" standard winch handles.  Features: Will not mar or scratch winch handles UV stabilized Easy to install Technical Specifications: Material - Soft PVC Color - White Dimensions (H x Base width x Top width) - 10" x 2.36" x 3.54" *Sold as an Individual

Read more less

Gear Grease - 3.5ozA plastic tube of waterproof grease for use in many applications.Features: Perfect for routine service and maintenance Aids the load-carrying characteristic of a winch *Sold as an Individual

Read more less

40mm Carbo Block with Spring & EyestrapLow-friction Carbo Air blocks are lightweight, strong, reliable—and affordable. Companions to the popular Harken Black Magic block line, these small, compact blocks have very high working loads for safe, easy trimming. Features: Sheave Ø (mm): 40 mm Sheave Ø (in): 1-9/16 in Maximum line Ø (mm): 10 mm Maximum line Ø (in): 3/8 in Maximum working load (kg): 220 kg Maximum working load (lb): 485 lb

Read more less

FRX10 Friction Ring - 10mm (25/64")Features: Efficient and light FRX Wichard thimbles are efficient, light, and reliable Very strong and can be used for heavy loads and semi-static lines FRX thimbles are designed to make your lines run smoothly with minimum wear They are hard anodized (50 microns) for a longer lifespan Applications:Mast-foot block, barber-hauler, inhauler, loop, thimble, lazy jack, running backstay, tackle, and moreSpecifications: Materials: Anodized aluminium Working load: (lb) 1760 / (kg) 800 Weight: (lb) 0.011/ (g) 5 A: (inch) 5/16" / (mm) 8 B: (inch) 25/64" / (mm) 10 C: (inch) 15/32" / (mm) 12 D diameter: (inch) 63/64" / (mm) 25 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Furling Drum - 3.74"Drums are molded from glass fiber reinforced nylon with stainless steel swivel and ball bearing assemblies. Furling drums will accept lines up to 4mm in diameter.Features:Holds up to 8.5M of LineSpecifications: Drum Diameter: 95mm Sail Area: 100 square foot Break Load: 1,108kg Safe Working Load: 554kg Weight: 281g
