Sailing

5mm Bow ShackleForged stainless steel shackles are polished to a high luster and are stamped with the screw pin diameter.Bow shackles are best for multidirectional loads. Their large interior opening allows plenty of articulation especially when attached to a round bail.Specifications: Shackle pin: 5mm / 3/16in Weight: 18g / 0.64oz Maximum working load: 540kg / 1190lb Breaking load: 1080kg / 2380lb

Read more less

22mm Double Micro BlockLow-friction Micro blocks are compact and lightweight. Specifications: Sheave: 22mm / 7/8in. Length: 51mm / 2in. Weight: 43g / 1.5oz. Maximum line: 6mm / 1/4in. Maximum working load: 159kg / 350lb Breaking load: 544kg/ 1200 lb

Read more less

29mm Carbo Air BlockLow-friction Carbo Air blocks are lightweight, strong, reliable—and affordable. Companions to the popular Harken Black Magic block line, these small, compact blocks have very high working loads for safe, easy trimming.Specifications: Sheave: 29mm / 1-1/8in Length: 49mm / 1-15/16in Weight: 23g / .8oz Shackle pin: 4mm / 5/32in Maximum line: 8mm / 5/16in Maximum working load: 150kg / 330lb Breaking load: 454kg / 1000lb

Read more less

Symmetric Carbin Hook - 120mm Length - 15/32"Features: Grade 316L stainless steel carbine hooks Symmetrical shape With eye to attach a webbing or a splicing Applications:For fastening applications Specifications: Materials: 316L stainless steel grade Working load: (lb) 2990 / (kg) 1360  WLL: (lb) 1580 / (kg) 720  Breaking load: (lb) 7930 / (kg) 3600  Weight: (lb) 0.505 / (g) 229  Dimensions: A: (inch) 53/64" / (mm) 21 B: (inch) 5/8" / (mm) 16 D diameter: (inch) 15/32" / (mm) 12 Length: (inch) 4 23/32" / (mm) 120 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Folding Pad Eye - Diameter 25/64"Features: Perfect solution for fastening applications (stay, blocks, jib tack point, lifeline, tether, etc...) Fully drop-forged product with outstanding working and breaking loads regardless of the angle of the load Modern and optimized design to suit the aesthetics of modern boats They can be folded down to minimize the risk of injuries The silicon pad eliminates noise and unpleasant vibrations Modern design Applications:For any fastening/attachment application: shroud, stay, blocks, lifeline, jib tack point, etc…)Specifications: Materials 17.4 pH stainless steel/316L stainless steel grade Working load (lb) 8990 Breaking load (lb) 19840 Weight (lb) 0.783 A (inch) 2 61/64" B (inch) 1 49/64" C (inch) 63/64" D (inch) 3 5/32" d diameter (inch) 25/64" D diameter (inch) 25/64" E (inch) 2 43/64" F (inch) 1 49/64"

Read more less

HR Snap Shackle with Thimble Eye - Length 3-3/4"Features: HR Forged snap shackle (Grade 17.4 PH stainless steel) with thimble eye Allows to splice the halyard directly onto the snap shackle (without using a thimble) Avoids the wear of the ropes Free rotation of the snap shackle thanks to the swivel eye The plunger pin is set captive into the hook and cannot become detached Excellent working and breaking loads > Easy to open by pulling the plunger pin (possibility to attach a lanyard) Applications: Snap shackle applications Allows to splice the halyard Applications requiring a free rotation of the snap shackle (for a better sail orientation) Specifications: Materials HR 17.4 PH stainless steel grade Length (inch) 3 3/4" Working load (lb) 2110 Breaking load (lb) 4400 Weight (lb) 0.168 A (inch) 5/8" B (inch) 15/32"

Read more less

Self-Locking Bow Shackle - Diameter 12mm - 15/32"Features: Self-locking bow shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking and batch number Applications: To be used when ample room is required Possibility to attach several lines or cables Specifications: Materials 316 stainless steel grade Working load (lb) 4580 WLL (lb) 2640 Breaking load (lb) 13220 Weight (lb) 0.514 Dimensions (see 2nd image): A (inch) 2-11/64" B (inch) 15/16" C (inch) 15/32" D (inch) 15/16" D diameter (inch) 15/32" E (inch) 25/64" M (inch) 2-31/64"

Read more less

Symmetric Carbin Hook Without Eye - Length 120mm - 15/32"Features: Grade 316L stainless steel carbine hooks Symmetrical shape without eye                                           Applications:For fastening applicationsSpecifications: Materials 316L stainless steel grade Length (inch) 4-23/32" Working load (lb) 2990 WLL (lb) 1670 Breaking load (lb) 8370 Weight (lb) 0.441 Dimensions (see 2nd image): A (inch) 53/64" B (inch) 5/8" D diameter (inch) 15/32"

Read more less

Eye strap - 10mm Diameter - 25/64" - 78mm Spacing - 3-5/64"Features: Complete range of drop-forged saddles with high-quality stainless steel (316L) Outstanding strength The round shape reduces the wear of the components connected to them (straps, ropes...) Applications: Fastening applications  Attachment of straps & cordage Specifications: Materials: 316L stainless steel grade Breaking load: (lb) 15430 / (kg) 7000  Weight: (lb) 0.165 / (g) 75  Dimensions: A: (inch) 25/32" / (mm) 20  B: (inch) 1 1/32" / (mm) 26  D diameter: (inch) 25/64" / (mm) 10  E: (inch) 3 5/64" / (mm) 78  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

HR Bow Shackle - 16mm Diameter - 5/8"Features:  Forged bow shackle in HR stainless steel grade (17,4 PH) Outstanding working and breaking load An HR shackle can be up to 60% more resistant than a shackle in 316L stainless steel WLL: only for industrial applications (lifting i.e…) CE marking Applications: Applications requesting high loads To be used when ample room is required Possibility to attach several lines or cables Do not use it for mooring applications Specifications:  Materials: HR 17.4 PH stainless steel grade Working load: (lb) 14990 / (kg) 6800  WLL: (lb) 8370 / (kg) 3800  Breaking load: (lb) 41880 / (kg) 19000  Weight: (lb) 1.16 / (g) 526  Dimensions: A: (inch) 2 3/4" / (mm) 70  B: (inch) 1 17/64" / (mm) 32  C: (inch) 5/8" / (mm) 16  D: (inch) 1 17/64" / (mm) 32  D diameter: (inch) 5/8" / (mm) 16  E: (inch) 19/32" / (mm) 15  M: (inch) 3 17/64" / (mm) 83  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 High Resistance (HR) *Sold as an Individual Quick Guide (pdf)

Read more less

Eye Strap - 8mm Diameter - 5/16" - 60mm Spacing - 2-23/64"Features: Complete range of drop-forged saddles with high-quality stainless steel (316L) Outstanding strength The round shape reduces the wear of the components connected to them (straps, ropes...) Applications: Fastening applications  Attachment of straps & cordage Specifications: Materials: 316L stainless steel grade Breaking load: (lb) 7710 / (kg) 3500  Weight: (lb) 0.084 / (g) 38  Dimensions: A: (inch) 5/8" / (mm) 16  B: (inch) 53/64" / (mm) 21  D diameter: (inch) 5/16" / (mm) 8  E: (inch) 2 23/64" / (mm) 60  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

HR D Shackle - Diameter 15/64"Features: Forged D shackle in HR stainless steel grade (17,4 PH) Outstanding working and breaking load An HR shackle can be up to 60% more resistant than a shackle in 316L stainless steel WLL: only for industrial applications (lifting i.e…) CE marking and batch number Applications Applications requesting high loads Standard applications of the shackle Attachment applications: blocks, head Do not use it for mooring applications Specifications: Materials HR 17.4 PH stainless steel grade Working load (lb) 2290 WLL (lb) 1010 Breaking load (lb) 5070 Weight (lb) 0.053 A (inch) 25/32" B (inch) 15/32" C (inch) 15/64" D (inch) 5/8" D diameter (inch) 15/64" E (inch) 9/32" F (inch) 1 13/16" G (inch) 1 13/16"

Read more less
