• Samlex 100W Fully Isolated DC-DC Converter - 4A - 9-18V Input - 24V Output [IDC-100A-24]
1 1

Samlex 100W Fully Isolated DC-DC Converter - 4A - 9-18V Input - 24V Output [IDC-100A-24]

$178.80
$223.40
$178.80
Shipping calculated at checkout.

SKU: CWR-67255   UPC: 622988067068

[COUNT] shoppers are looking at this right now

    100W Fully Isolated DC-DC Converter - 4A - 9-18V Input - 24V Output

    IDC-100 series is a complete line of high efficiency 100 Watt isolated DC-DC converters suitable for applications requiring galvanic isolation between the input and the output. IDC-100A-24 isolated DC-DC converter provides a highly regulated output DC voltage of 24.5 Volts for an input DC voltage range of 9-18 Volts and rated output current of 4 Amps (at 18 Volts input). Features of this isolated DC-DC converter include compact housing, fold-back current limiting and protection against short circuit, overheating, overvoltage and reverse polarity connection. The unit comes with 1/4” push-on flat blade “quick disconnect” connectors. IDC-100A-24 isolated DC-DC converter is EMI/EMC compliant and conforms to European standards EN50081-1 (for EMI), EN50082-1 (for EMC) and the European Automotive Directive 95/54/CE.

    Features:

    • Fully Isolated
    • Short Circuit Protected
    • Current Limited
    • CE Approved
    • 2 Year Warranty

    Specifications:

    • Input: 9.2-18 VDC
    • Output: 24 VDC
    • Watts: 100
    • Amps: 4 Amps
    • Weight: 1.2 (lbs)
    • Weight: 0.54 (kg)
    • Dimensions: 6 x 3.5 x 1.9 (in)
    • Dimensions: 15.2 x 8.9 x 4.8 (cm)
    • Safety: CE
    • Warranty: 2 Year Limited

    Applications:

    • Earth moving equipment
    • Heavy trucks
    • Buses
    • Marine vehicles
    • CB radios
    • 24 Volt lighting systems
    • AM/FM sound systems

    WarningWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.


    Owner's Manual (pdf)
    Brochure (pdf)
