8mm Eye Nut - 1/2" DiameterFeatures: A complete range of single-piece forged products for fastenings applications Outstanding breaking loads Available in different sizes Applications: Various fastening applications Towing application Waterskiing lines attachment Specifications: Materials: 316L stainless steel grade Breaking load: (lb) 4850 / (kg) 2200  Weight: (lb) 0.044 / (g) 20  Dimensions: A: (inch) M8 x125 / (mm) M8 x125  B: (inch) 33/64" / (mm) 13  C: (inch) 1 1/16" / (mm) 27  D: (inch) 15/64" / (mm) 6  E: (inch) 43/64" / (mm) 17  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Thimble Shackle - Allen Head Pin - 8mm Diameter - 5/16"Features: Thimble shackle with allen head pin forged in grade 316L stainless steel Allows to spliced a rope without adding and additional thimble With the captive pin, no risk to lose the pin Outstanding working and breaking loads Applications: Mainsheet halyards Max rope size: 12 mm Specifications: Materials: 316 stainless steel grade Working load: (lb) 2200 / (kg) 1000  Breaking load: (lb) 6610 / (kg) 3000  Weight: (lb) 0.168 / (g) 76  Dimensions: A: (inch) 1 39/64" / (mm) 41  B: (inch) 5/8" / (mm) 16  C: (inch) 5/16" / (mm) 8  D: (inch) 5/8" / (mm) 16  D diameter: (inch) 5/16" / (mm) 8  E: (inch) 9/32" / (mm) 7  F: (inch) 2 63/64" / (mm) 76  G: (inch) 1 19/64" / (mm) 33  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

HR Quick Release Snap Shackle With Large Bail-110mm Length - 4-21/64"Features: HR forged (17.4 PH) quick-release snap shackle with large bail The opening is made by pulling the lanyard Perfect to attach several lines (spinnaker sheets...) Outstanding working and breaking loads Free rotation of the snap shackle thanks to the swivel Applications: For spinnaker operations Perfect to attach several lines: spinnaker sheets... Specifications: Materials: HR 17.4 PH stainless steel grade Working load: (lb) 3520 / (kg) 1600  Breaking load: (lb) 6610 / (kg) 3000  Weight: (lb) 0.353 / (g) 160  Dimensions: A: (inch) 25/32" / (mm) 20  B: (inch) 1 3/64" / (mm) 26.5  Length: (inch) 4 21/64" / (mm) 110  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 High Resistance (HR) *Sold as an Individual Quick Guide (pdf)

Read more less

Self-Locking Allen Head Pin D Shackle - 12mm Diameter - 15/32"Features: Self-locking shackle with allen head pin D forged in grade 316L stainless steel The pin is locked into one of the indentations The head of the pin does not stick out from the shackle body and thus eliminates any risk of snagging No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking Applications: Ideal to link chains and anchor On the halyard, avoids damaging the sails To be used when the clutter is reduced Specifications: Materials: 316 stainless steel grade Working load: (lb) 4580 / (kg) 2080  WLL: (lb) 2640 / (kg) 1200  Breaking load: (lb) 13220 / (kg) 6000  Weight: (lb) 0.412 / (g) 187  Dimensions: A: (inch) 1 17/32" / (mm) 39  B: (inch) 15/16" / (mm) 24  C: (inch) 15/32" / (mm) 12  D: (inch) 15/16" / (mm) 24  D diameter: (inch) 15/32" / (mm) 12  E: (inch) 25/64" / (mm) 10  F: (inch) 2 7/8" / (mm) 73  G: (inch) 1 59/64" / (mm) 49  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load.WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Self-Locking D Shackle - 12mm Diameter - 15/32"Features: Self-locking D shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking Applications: Standard applications of the shackle Attachment applications: blocks, head Specifications: Materials: 316 stainless steel grade Working load: (lb) 4580 / (kg) 2080 WLL: (lb) 2640 / 1200 (kg) Breaking load: (lb) 13220 / (kg) 6000  Weight: (lb) 0.425 / (g) 193 Dimensions: A: (inch) 1-21/32" / (mm) 42  B: (inch) 1-1/16" / (mm) 27  C: (inch) 15/32" / (mm) 12  D: (inch) 15/16" / (mm) 24  D diameter: (inch) 15/32" / (mm) 12  E: (inch) 7/16" / (mm) 11  F: (inch) 2-7/8" / (mm) 73  G: (inch) 2-7/16" / (mm) 62   Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Not Self-Locking Bow Shackle - 16mm Diameter - 5/8"Features:  Bow shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking Part # 01247 is not self-locking   Applications:  To be used when ample room is required Possibility to attach several lines or cables Specifications:   Materials: 316 stainless steel grade Working load: (lb) 7050 / (kg) 3200  WLL: (lb) 4400 / (kg) 2000  Breaking load: (lb) 22040 / (kg) 10000  Weight: (lb) 1.19 / (g) 540 Dimensions:   A: (inch) 2 3/4" / (mm) 70  B: (inch) 1 17/64" / (mm) 32  C: (inch) 35/64" / (mm) 14  D: (inch) 1 17/64" / (mm) 14  D diameter: (inch) 5/8" / (mm) 16  E: (inch) 19/32" / (mm) 15  M: (inch) 3 11/32" / (mm) 85  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load.WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Not Self-Locking D Shackle - 14mm Diameter - 9/16"Features:  D shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking Part #01207 is not a self-locking D shackle  Applications: Standard applications of the shackle Attachment applications: blocks, head Specifications:  Materials: 316 stainless steel grade Working load: (lb) 5290 / (kg) 2400  WLL: (lb) 3520 / (kg) 1600  Breaking load: (lb) 17630 / (kg) 8000  Weight: (lb) 0.688 / (g) 312  Dimensions: A: (inch) 1 27/32" / (mm) 47  B: (inch) 1 7/64" / (mm) 28  C: (inch) 35/64" / (mm) 14  D: (inch) 1 7/64" / (mm) 28  D diameter: (inch) 35/64" / (mm) 14  E: (inch) 33/64" / (mm) 13  F: (inch) 3 15/64" / (mm) 82  G: (inch) 3 5/64" / (mm) 78  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load.WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

U-Bolt Pad Eye - 12mm Diameter - 15/32" - 130mm Length - 5-1/8"Features: Entirely drop forged product with high-quality stainless steel Outstanding working and breaking loads For any fastening applications (shrouds, lifelines, blocks...) Delivered with bolts and counter-plate Max tightening torque: 60 Nm Applications:Various fastening applications: shrouds, lifelines, blocks…Specifications: Materials: 316L stainless steel grade Working load: (lb) 14100 / (kg) 6400   Breaking load: (lb) 22040 / (kg) 10000  Weight: (lb) 0.769 / (g) 349  Dimensions: A: (inch) 1 47/64" / (mm) 44  B: (inch) 1 11/32" / (mm) 34  C: (inch) 2 3/4" / (mm) 70  D diameter: (inch) 15/32" / (mm) 12  Length: (inch) 5 1/8" / (mm) 130  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

U-Bolt Pad Eye - 10mm Diameter - 25/64" - 110mm Length - 4-21/64"Features: Entirely drop forged product with high-quality stainless steel Outstanding working and breaking loads For any fastening applications (shrouds, lifelines, blocks...) Delivered with bolts and counter-plate Max tightening torque: 36 Nm Applications:Various fastening applications: shrouds, lifelines, blocks…Specifications: Materials: 316L stainless steel grade Working load: (lb) 7930 / (kg) 3600  Breaking load: (lb) 15430 / (kg) 7000  Weight: (lb) 0.489 / (g) 222  Dimensions: A: (inch) 1 37/64" / (mm) 40  B: (inch) 1 17/64" / (mm) 32  C: (inch) 2 9/16" / (mm) 65  D diameter: (inch) 25/64" / (mm) 10  Length: (inch) 4 21/64" / (mm) 110  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Double Folding Pad Eye - 8mm Diameter - 5/16"Features: Fully drop forged product with outstanding working and breaking loads regardless of the angle of the load Perfect solution attachment (stay, blocks, jib tack point) Possibility to attach several stays Modern and optimized design to suit the aesthetics of modern boats They can be folded down to minimize the risk of injuries The silicon pad eliminates noise and unpleasant vibrations Applications: For any fastening/attachment application Allows to attach several shrouds  Specifications: Materials: 316L stainless steel grade Working load: (lb) 5290 / (kg) 2400  Breaking load: (lb) 9470 / (kg) 4300  Weight: (lb) 0.556 / (g) 252  Dimensions: A: (inch) 2 21/64" / (mm) 59  B: (inch) 1 3/8" / (mm) 35  C: (inch) 43/64" / (mm) 17  d diameter: (inch) 21/64" / (mm) 8.5  D diameter: (inch) 5/16" / (mm) 8  E: (inch) 3 3/16" / (mm) 81  F: (inch) 2 21/64" / (mm) 59  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Webbing Eye Strap - 4mm Diameter - 5/32" - 56mm Spacing - 2-13/64"Features: Drop-forged webbing eye straps with high-quality stainless steel (316L) Outstanding strength Specific use for webbing Applications:The perfect solution to attach webbingSpecifications: Materials: 316L stainless steel grade Weight: (lb) 0.015 / (g) 7  Dimensions: A: (inch) 1 7/64" / (mm) 28  B: (inch) 13/64" / (mm) 5  D diameter: (inch) 5/32" / (mm) 4  E: (inch) 2 13/64" / (mm) 56  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Eye Strap - 4mm Diameter - 5/32" - 30mm Spacing - 1-17/64"Features: Complete range of drop-forged saddles with high-quality stainless steel (316L) Outstanding strength The round shape reduces the wear of the components connected to them (straps, ropes...) Applications: Fastening applications  Attachment of straps & cordage Specifications: Materials: 316L stainless steel grade Breaking load: (lb) 1430 / (kg) 650  Weight: (lb) 0.009 / (g) 4  Dimensions: A: (inch) 5/16" / (mm) 8  B: (inch) 7/16" / (mm) 11  D diameter: (inch) 5/32" / (mm) 4  E: (inch) 1 17/64" / (mm) 32  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less
