HRC10 Horizontal Rope Chain Windlass - 12V Capstan 3/8" Chain, 5/8" RopeMaxwell's HRC10 represents yet another breakthrough in performance and anchor handling excellence. The horizontal, fully automatic rope/chain windlasses has been designed to meet the demands for use on larger vessels up to 16 meters (52'), which require a completely above deck installation system. The HRC10 handles 5/8" rope and 3/8" chain, including the thick rope to chain splice. The modern appearance of the HRC10 retains the classic good looks of previous Maxwell horizontal windlasses, while incorporating design features years ahead of its competitors.The HRC10 windlass is fitted with Maxwell's unique Wave Design™ chainwheel. The rope/chain wheel incorporates two unique design concepts that greatly improve the handling and control of the rope/chain spliced rode. The outer ribs of the chainwheel are angled slightly forward ensuring that the rope and the chain are smoothly guided in the wheel during anchor retrieval.As the rope pulls into the wheel, the opposite facing inner ribs grip the rope in an undulating manner, securing the rope more firmly in a 'wave pattern' action that is far superior to the traditional 'jam cleat' manner of holding the rope. Not only does this Wave Design™ hold the rope more securely, it is also kinder on the rope resulting in increased longevity of your anchor rode.Features: Aesthetically pleasing above deck design, evolved from the philosophy of form follows function, encapsulates the motor and drive in a two part watertight case, saving space below deck 2-part case consists of a die cast, marine-grade hard anodised alloy front section and a rugged and easily removable composite motor cover aft section 2-piece watertight case allows for quick and easy, on-deck, routine maintenance Simple "bolt down" installation ensures effortless and rapid on-deck installation and set up Stainless steel pressure arm always exerts maximum control pressure on the rode (rope, splice or chain) Wave Design™ chainwheel is able to accommodate a wide range of chain pitch differences, within the specified chain size diameters, suitable for use with the HRC10 Unique Maxwell "wrap around"™ horizontal chainwheel ensures that more than 90° of the wheel is used, allowing greatly improved rope and chain handling compared with competitor designs Works just as effectively with all-chain rodes for those who desire the added security and holding power of an all-chain anchor system The integral chain pipe and huge, through deck hawse pipe throat ensures easy entry of the rope/chain rode into and out of the anchor locker Cone type clutch/brake mechanism permits manual, "free fall"™ anchoring and emergency crank recovery of the rode and anchor if required The sealed oil bath and marine-grade hard anodised, alloy gearbox provides high efficiency output drive via precision worm and wormwheel Specifications: Chain - Diameter (Inches): 3/8" Freefall: Yes Rope Diameter (Inches): 5/8" Vertical/Horizontal: Horizontal Box Dimensions: 11"H x 17"W x 20"L WT: 55 lbs UPC: 1000000002638 Brochure (pdf)

Read more less

Capstan 300Part #: P77726Versatile rope winch for anchoring, sailing & fishingThe Capstan 300 is a smaller power assisted rope capstan for a variety of uses. It has a maximum pull of 300 lbs with a retrieval speed of 85 feet per minute. Whether anchoring, sailing, or fishing, let the Capstan 300 help spare your back, speed up your retrieval process, and make your boating more pleasurable. Features: Strong pulling power of 300 lbs Quick retrieval speed of 85 ft/minute Deck mounted design - saves space for rope locker Easy to operate footswitch (included) Handles unlimited rope lengths All aluminum housing with a durable polyester paint finish Stainless steel internal shafts, fasteners, & hardware Specifications: Freefall: No Rope Diameter (Inches): 5/8" Vertical/Horizontal: Horizontal Box Dimensions: 9"H x 11"W x 16"L WT: 19.8 lbs UPC: 000000166102

Read more less

V1 Fast Fit Motor Gearbox Assembly - 12 VReplacement motor/gearbox assembly for V1 - 12 V windlasses.Compatible With: V1 windlasses*Sold as an Individual

Read more less

CapstansWhy Capstans?Rather than using the hand-over-hand method of retrieving lines, the capstan offers a mechanical advantage that is both faster and safer. The capstan does the heavy lifting with only a small amount of effort. The maximum speed of the line retrieval depends on the rotational speed of the drum. The benefit is that the retrieval speed can be adjusted by decreasing the tension on the retrieved line, maintaining control over a very heavy load with little effort.This useful device, which has been around since the early days of sailing, is still used today. Recreational fishermen, like commercial fishermen, use these for hauling crab and lobster pots and there are many other uses aboard boats. The few mechanical parts and ease of use have made this a favorite of fisherman worldwide. While chains should NEVER be wrapped around a drum, the majority of lines can be handled on a capstan.A capstan, typically operated by an easy to use footswitch (R001459), allows the boater to control lines with ease without having additional crew members. Powerwinch has a model to fit your needs. All Powerwinch capstans come with a foot control switch that allows for hands-free operation.Capstan 1000Multi-purpose rope winch for anchoring, sailing & Fishing1000 pounds of pulling power!Our largest capstan, the Capstan 1000, is a power assisted rope capstan for larger applications with 1000 pound pull power and 40 ft/minute retrieval speed. A great tool for quick retrieval lobster, prawn and crab pots. The Capstan 100 also provides power assist for limited crew sailboats and power assisted anchor retrieval. Uses up to 3/4" diameter rope. Fast 40'/min retrieval speed 1000 lb max pulling power Handles unlimited rope lengths Easy to operate footswitch (included) All aluminum housing with a durable polyester finish Thermal automatic resetting circuit breaker One piece, heat-treated and oil-impregnated gears Stainless steel internal shafts, fasteners, and hardware Two year limited warranty Specifications: Rope Diameter (Inches): 3/4" Vertical/Horizontal: Horizontal Freefall: No Box Dimensions: 9"H x 11"W x 15"L WT: 20.9 lbs UPC: 033936770990 Owner's Manual (pdf)

Read more less

Class 46'Automatic Helm-Operated Free-Fall WindlassThe Safest Way to Anchor! Free-Fall System anchors up to 300'/min - Up to four times faster than powering down Exclusive stainless steel rope & chain guidance system - Durable materials stand up to years of use Ultra smooth motor uses less amps - Free-fall does not need battery power so it preserves your battery Built with durable stainless steel fasteners - Resists corrosion for easy removal Watertight seals - For additional protection against corrosion One piece motor plate - For smooth power transmission & improved gear life Heat treated oil-impregnated gear systems -Smoother operation, resists corrosion, lasts longer Stainless steel drive shafts - For years of smooth, reliable performance Replaceable Rode-Glide - Smoothly channels rope and chain below deck Use tapered back splice - For smooth rope-to-chain transition Specifications: Freefall: Yes Rope Diameter (Inches): 5/8" Vertical/Horizontal: Horizontal Box Dimensions: 9"H x 11"W x 15"L WT: 23.1 lbs UPC: 033936777463 Owner's Manual (pdf)

Read more less

Cone and Washer Kit v/CPX and V Series Windlasses Replacement cones and washers for CPX and V series windlasses.Compatible With:CPX and V Series windlassesIn the Box: Cones x two (2) Washers x two (2)  Instruction manual  *Sold as an Indivudual

Read more less

V4/V5 Windlass Gypsy #203 Replacement gypsy on Windlass Model V4/V5Features: Rope-chain gypsy Cone clutch for smooth, easy control Manual Free Fall W.A.R.P Drum Robust and reliable drivetrain Manual override (optional) Technical Specifications: Rope Size - 5/8" (16 mm) (3 strand hard lay up) Chain Size - 3/8" (10 mm) ( Campbell S3, Lewmar 9.5mm G40) *Sold as an Individual

Read more less

Pro-Fish 1000 Horizontal Windlass Kit - 12VLewmar's Pro-Fish model is the ultimate windlass for fishermen.  The Pro-Fish has an automatic freefall that allows you to pull right up over a wreck or ledge, and drop anchor with speed and precision.  No more running your motor or wasting fuel while you hover fish.  You can retrieve your anchor just as easily, with the push of a button. Plus, the Pro-Fish is DIY-ready and made of durable 316 stainless steel.The Pro-Fish is perfectly suited to installation in the stern of a boat, where it can be utilized for easy Scandinavian-style stern anchoring.  The automatic free-fall mechanism means access to the windlass is not required to drop or retrieve the anchor and the all-stainless design is extremely resistant to corrosion.This windlass has been specially designed to suit leaded lines up to 5/8" in diameter and a revised control arm and new Pro-Guard plate prevent the rope from jumping out of the windlass or snagging during operation.Features: Automatic freefall Powerful motor providing fast line speed Manual emergency recovery equipped all you need is a common 1/2 socket wrench Convenient above-deck installation Technical Specifications: Chain Size - 5/16" G4 or BBB Rope Size - 5/8" 3-strand or 8-plait Motor Voltage - 12 Volt DC Motor Power - 700 Watt Maximum pulling power - 1000lb (453kg) Maximum Working Load - 250lb (113.4kg) For boats up to 38' (11.58M) In the Box: Windlass Base gasket Mounting hardware Circuit breaker Dual-direction solenoid Rocker switch Instruction manual  *Sold as an Individual Specifications: Freefall: Yes Vertical/Horizontal: Horizontal Box Dimensions: 9"H x 12"W x 13"L WT: 20 lbs UPC: 743683326677 Owner's Manual (pdf)

Read more less

DeckHand™ 25#1810125The DeckHand 25 has a 25-lb anchor capacity (anchor not included). Includes davit for stowing most styles of anchors. Pre-spooled with 60 feet of 800-lb test nylon rope. Runs on 12-volt battery (not included). Get precision boat placement and the ability to stay on the fish as long as you want with a DeckHand™ electric anchor winch. It automatically raises or lowers your anchor at the touch of a button, and its special anti-drag system senses the bottom to allow for controlled drifting.Features 25-lb anchor capacity (anchor not included) Pre-spooled with 60 feet of 800-lb test nylon rope Davit can be mounted at base of DeckHand or in remote position on deck Davit stows most kinds of anchors Stow and deploy switch integrated into the base of the unit Auto-drift feature automatically stops the motor when the anchor touches bottom (or hits an obstacle); when slack in teh rope becomes tight, rope is automatically released; lock the winch with the touch of a button Consistent hold pattern with older DeckHand models (DH-18, DH-20, DH-35) Includes: remote mountable anchor davit WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Rope Diameter (Inches): 3/16" Vertical/Horizontal: Horizontal Freefall: No Box Dimensions: 9"H x 11"W x 15"L WT: 12.8 lbs UPC: 029402027897 Owner's Manual (pdf)

Read more less

HRC10 Horizontal Rope Chain Windlass - 12V No Capstan 3/8" Chain, 5/8" RopeMaxwell's HRC10 represents yet another breakthrough in performance and anchor handling excellence. The horizontal, fully automatic rope/chain windlass has been designed to meet the demands for use on larger vessels up to 16 meters (52'), which require a completely above deck installation system. The HRC10 handles 5/8" rope and 3/8" chain, including the thick rope to chain splice. The modern appearance of the HRC10 retains the classic good looks of previous Maxwell horizontal windlasses, while incorporating design features years ahead of its competitors.The HRC10 windlass is fitted with Maxwell's unique Wave Design™ chainwheel. The rope/chain wheel incorporates two unique design concepts that greatly improve the handling and control of the rope/chain spliced rode. The outer ribs of the chainwheel are angled slightly forward ensuring that the rope and the chain are smoothly guided in the wheel during anchor retrieval.As the rope pulls into the wheel, the opposite facing inner ribs grip the rope in an undulating manner, securing the rope more firmly in a 'wave pattern' action that is far superior to the traditional 'jam cleat' manner of holding the rope. Not only does this Wave Design™ hold the rope more securely, it is also kinder on the rope resulting in increased longevity of your anchor rode.Features: Aesthetically pleasing above deck design, evolved from the philosophy of form follows function, encapsulates the motor and drive in a two part watertight case, saving space below deck 2-part case consists of a die cast, marine-grade hard anodised alloy front section and a rugged and easily removable composite motor cover aft section 2-piece watertight case allows for quick and easy, on-deck, routine maintenance Simple "bolt down" installation ensures effortless and rapid on-deck installation and set up Stainless steel pressure arm always exerts maximum control pressure on the rode (rope, splice or chain) Wave Design™ chainwheel is able to accommodate a wide range of chain pitch differences, within the specified chain size diameters Unique Maxwell "wrap around"™ horizontal chainwheel ensures that more than 90° of the wheel is used, allowing greatly improved rope and chain handling compared with competitor designs The HRC10 works just as effectively with all-chain rodes for those who desire the added security and holding power of an all-chain anchor system The integral chain pipe and huge, through deck hawse pipe throat ensures easy entry of the rope/chain rode into and out of the anchor locker Cone type clutch/brake mechanism permits manual, "free fall"™ anchoring and emergency crank recovery of the rode and anchor if required= The sealed oil bath and marine-grade hard anodised, alloy gearbox provides high efficiency output drive via precision worm and wormwheel Specifications: Chain - Diameter (Inches): 3/8" Freefall: Yes Rope Diameter (Inches): 5/8" Vertical/Horizontal: Horizontal Box Dimensions: 12"H x 17"W x 20"L WT: 48.2 lbs UPC: 1000000002645 Brochure (pdf)

Read more less

The RC6 utilizes 6mm/7mm (1/4") chain spliced to 12mm (1/2") three strand or 8-plait rope. Maximum Pull: 660lbs. Providing most of the features of the larger RC8, the RC6 has been designed with the smaller, trailer boat market in mind. The in-line, vertical gearbox and motor means quick and easy installation by either the boat yard or the DIY aftermarket customer. An inexpensive, high performance and great looking windlass: the RC6 is built for durability and years of trouble free use. The RC6 is available only as a low profile unit (no optional capstan drum).Kits include:windlass , an on/off breaker panel, a reversing soleniod, an up/down panel switch and a handle. Specifications: Chain - Diameter (Inches): 1/4" Rope Diameter (Inches): 1/2" Vertical/Horizontal: Vertical Box Dimensions: 10"H x 15"W x 15"L WT: 25 lbs UPC: 1000000004816 Brochure (pdf)

Read more less

The all new compact HRC6 and HRC8 are Maxwell's horizontal versions of the latest innovative new vertical RC6 and RC8 automatic rope/chain windlasses. The new HRC6 and HRC8 are packed with original and proven features including rode management technology developed by Maxwell.HRC8 Simple "bolt down" installation ensures effortless and rapid on-deck installation and set up Guaranteed trouble free rode transition from rope to chain, by means of an innovative, proven and patented pressure arm system, within a safe enclosed design Integrated composite nylon, through deck hawse pipe for ease of installation and smooth, snag-free operation High efficiency spur gearbox incorporating a robust non-backwind mechanism High speed, jam-free retrieval of rope and chain controlled from a remote panel mounted Up/Down switch Emergency "free fall" function in the event of onboard power failure Revolutionary new chainwheel - see over Heavy duty, dual direction motor incorporating new technology features, including integrated wiring for quick electrical installation, is easily removed for simple routine electric brush maintenance Now incorporating Maxwell's automatic free-fall technology. Simply activate the windlass 'free fall' lever, operate your down control (helm station or footswitch) and the windlass will freefall your anchor. Ready to lift the anchor? Activate the up control and the 'free fall' device automatically disengages allowing you to power up your anchor Aesthetically pleasing above deck design, encapsulating the motor and drive in a watertight case, saving space below deck and allowing simple routine maintenance Die cast, marine-grade, alloy case is hard anodized for unsurpassed marine protection Kits include:windlass, on/off breaker panel, reversing soleniod, up/down panel switch, a clutch release handle Specifications: Model: HRC8 Maximum Pull: 900lbs Chain Short Link: 5/16" Rope Size (Nylon): 9/16" Line Speed(Anchor Retrieval): 108'/min Power Supply(DC): 12V Motor Power: 600W Net Weight: 25lbs Specifications: Chain - Diameter (Inches): 5/16" Freefall: Yes Rope Diameter (Inches): 9/16" Vertical/Horizontal: Horizontal Box Dimensions: 10"H x 14"W x 15"L WT: 29 lbs UPC: 9414761104029 Brochure (pdf)
