Sailing

Quick Release Pin - 5/16" x 1" GripQuick Release Pin, 5/16" x 1.0" Grip. 316 Stainless Steel. Safe Working Load 3000 lbs.

Read more less

Stainless Steel Welded Pad Eye - 2-1/4"L x 5/8"WSpecifications: Eye Width 1/2" (13 mm) Eye Height 1/2" (13 mm) Eye Stock 1/4" (6 mm) Length 2-1/4" (57 mm) Width 5/8" (16 mm) Fasteners (2), #10 RH (5 mm) C/C 1-11/16" (42 mm) SWL 750 lbs. (350 kg) Weight 1.75 oz. (50 g) Specifications: Color: Stainless Box Dimensions: 1"H x 2"W x 4"L WT: 0.05 lbs UPC: 740507007804

Read more less

Clamp-On Furling Line Stanchion Lead Block - 1" Ball BearingDelrin™ ball bearing sheave allows for quick and easy furling line adjustment. Stainless steel cage and strap ensure durability. Specifications: Stanchions 1" (25mm) in diameter 1-7/16" (37mm) Sheave Diameter Maximum 1/2" (12mm) line size Safe Working Load = 1000 lbs (450kg)

Read more less

Deck Organizer - Size 2 - 2 Sheave - Black Designed for use when diverting mast base control lines and halyards back to the cockpit.  Allowing the crew to sail from the security of the cockpit.Suitable for boats up to 32' (9.75 M) with halyard size up to 9/16"Deck organizers can be double stacked.Technical Specifications: Material - Spectro Anodized Aluminum  Dimensions (L x W x H) - 5.83" x 1.5" x 1.1" (148 x 38 x 28 mm)  Weight -  7.23 oz  (205 g)   Sheave Material - Molded Acetal Sheave Diameter - 1.73" (44 mm) Sheave Width - .71" (18 mm) Maximum Line Diameter - .55" (14 mm) *Sold as an Individual  Brochure (pdf)

Read more less

Size 2 Double Stanchion Lead BlockBarton Marine's stanchion lead blocks have proven to be popular with Cruising sailors all over the World. Mounted onto the stanchion base, the stanchion lead block enables the Genoa furling line to be led back to the cockpit for easy adjustment. Ball bearing sheaves have a precision molded acetal sheave running on a large diameter brass bearing, ensuring free running under the highest of loads.   The unit will fully rotate about the swivel head to match your pulling angle. Block attachment to stanchion is by means of screwing together the integral Stainless Steel strap.Technical Specifications Sheave - Double Sheave Size - 1-3/8" (35mm) Maximum Rope Diameter -  5/16" (8mm) Safe Working Load - 815 lb (370 kg) Maximum Stanchion (Tube) Size - 1" (25mm)  *Sold as an Individual Quick Guide (pdf)Brochure (pdf)

Read more less

Single Fixed EyePlain Bearing BlocksBarton plain bearing blocks have a precision molded acetal sheave running on a large diameter brass bearing, ensuring free running under the highest of loads.Specifications Sheave size: 20mm x 8mm Max rope diameter: 5mm Safe working load: 275kg / 606lbs Breaking load: 550kg / 1210lbs Length: 39.1mm Weight: 13g

Read more less

Size 1 Deck Organizer - 4 SheaveDesigned for use when diverting mast base control lines and halyards back to the cockpit.  Allowing the crew to sail from the security of the cockpit.Suitable for boats up to 32' (9.75 M) with halyard size up to 7/16"Deck organizers can be double-stacked.Technical Specifications: Material - Spectro Anodized Aluminum  Dimensions (L x W x H) - 7.87" x 1.1" x 1" (200 x 28 x 25 mm)  Weight -  7.05 oz  (200 g)   Sheave Material - Molded Acetal Sheave Diameter - 1.26" (32 mm) Sheave Width - .67" (17 mm) Maximum Line Diameter - .47" (12 mm) *Sold as an Individual  Quick Guide (pdf)Brochure (pdf)

Read more less

Size 2 Single Cheek BlockPlain Bearing BlocksBarton plain bearing blocks have a precision molded acetal sheave running on a large diameter brass bearing, ensuring free running under the highest of loads.Specifications Sheave size: 35mm x 12mm Max rope diameter: 8mm Safe working load: 370kg / 815lbs Breaking load: 740kg / 1630lbs Length: 80mm Weight: 73g

Read more less

Size 1 Single Swivel Block with BecketWith the unique super-low friction ball race systems, featuring acetal sheaves and delrin ball bearings, running on a large diameter center boss. This allows us to fit more load-bearing balls, which ensure extremely low friction performance, even under high loads.Specifications: Sheave size: 20mm x 8mm Max rope diameter: 5mm Safe working load: 275kg / 606lbs Breaking load: 550kg / 1210lbs Length: 39.1mm Weight: 13g

Read more less

Pillar Fairlead for 70300 Cam CleatThis add-on enables the cam cleat to be engaged from a variety of angles. Cams can be fitted either way around to achieve a lead from in front or behind.Features: Made for Barton’s 70300 Maxi Cam Cleat Stainless steel pillars to add strength and wear resistance

Read more less

Pillar Fairlead for 70200 Cam CleatThis add-on enables the cam cleat to be engaged from a variety of angles. Cams can be fitted either way around to achieve a lead from in front or behind.Features: Made for Barton’s 70200 Midi Cam Cleat Stainless steel pillars to add strength and wear resistance

Read more less

Kevlar Cam Cleat MidiManufactured from a composite Kevlar/Zytal material, this advanced material offers performance advantages over carbon fiber and conventional glass-reinforced resins; 'K' cams are very strong, lightweight, and have excellent wear resistance. A progressive tooth design ensures maximum holding power on all types of lines while maintaining minimum wear to both cam and line.Specifications: Max Line Ø: 6 mm - 12 mm (0.4 - 0.55 inches) Fastenings Ø: 5 mm (0.20 in.) Fastenings Center: 40 mm (1.57 in.) Holding Power: 230 kg (507.1 lbs) Weight: 34 kg (74.96 lbs)

Read more less
