Size 3 Single Plain Bearing Block with SwivelBarton plain bearing blocks have a precision molded acetal sheave running on a large diameter brass bearing, ensuring free running under the highest of loads.Features: Fully swiveling head with removable shackle For use on dinghies, day boats, and light cruising yachts Specifications & Dimensions: Length: (mm) 100 / (inch) 3-15/16" Weight (grams): 73 g. Single (mm) 45 x 13 / (inch) 1-3/4" x 1/2" Max Rope Diameter: (mm) 10 / (inch) 3/8" SWL: (kg) 400 / (lbs.) 881 Break Load: (kg) 800 / (lbs.) 1763 Note: break loads where break and safe working loads are stated, it is assumed that all sheaves are evenly loaded as in a purchase tackle

Read more less

Size 3 Stanchion Lead Block - Single with Becket & Cam Cleat Barton Marine's stanchion lead blocks have proven to be popular with Cruising sailors all over the World.  Mounted onto the stanchion base, the stanchion lead block enables the Genoa furling line to be led back to the cockpit for easy adjustment. Ball bearing sheaves have a precision molded acetal sheave running on a significant diameter brass bearing, ensuring free running under the highest loads.   The unit will fully rotate about the swivel head to match your pulling angle. Cam cleat will secure the line into place.  Block attachment to stanchion is by means of screwing together the integral Stainless Steel strap.Technical Specifications Sheave - Single Sheave Size - 1-3/4" (45mm) Maximum Rope Diameter -  3/8" (10mm) Safe Working Load - 881 lb (400 kg) Maximum Stanchion (Tube) Size - 1" (25mm)  *Sold as an Individual  Quick Guide (pdf)Brochure (pdf)

Read more less

ClamSealThe ClamSeal™ can instantly repair splits and tears up to 3.5" (90mm) in length without using any hand tools or adhesives.ClamSeal™ is a glueless repair system that instantly repairs small tears or splits in inflatables above or below the waterline, regardless of the fact that the material may be wet.The system works by using two half 'shells' that screw together tightly, using the inflatable material itself as a water and air-tight seal.  It is quick and easy to fit and provides an immediate repair that keeps you afloat until a more permanent repair can be made.The ClamSeal™ can be carried as part of your emergency equipment onboard.  It can be used at sea, on shore, and even underwater as no adhesive or tape is involved.  The clever mechanics of the ClamSeal™ design mean this simple product can keep you safely afloat.Compatible With: RIBs Dinghies Liferafts Buoyancy bags Virtually any inflatable product Features: Quick and easy to fit Requires no adhesive or tape Can be used above or below the waterline Provides an instant repair Reusable again and again *Sold as an Individual  Brochure (pdf)

Read more less

Deck Organizer - Size 1 - 6 Sheave Designed for use when diverting mast base control lines and halyards back to the cockpit.  Allowing the crew to sail from from the security of the cockpit.Suitable for boats up to 32' (9.75 M) with halyard size up to 7/16"Deck organizers can be double stacked.Technical Specifications: Material - Spectro Anodized Aluminum  Dimensions (L x W x H) - 11.3" x 1.1" x 1" (287 x 28 x 25 mm)  Weight -  10.41 oz  (295 g)   Sheave Material - Molded Acetal Sheave Diameter - 1.26" (32 mm) Sheave Width - .67" (17 mm) Maximum Line Diameter - .47" (12 mm) *Sold as an Individual  Quick Guide (pdf)Brochure (pdf)

Read more less

Small Furling Drum - 2.99"Drums are molded from glass fiber reinforced nylon with stainless steel swivel and ball bearing assemblies. Furling drums will accept lines up to 4mm in diameter.Features:Holds up to 4.3M of LineSpecifications: Drum Diameter: 76mm Sail Area: 60 square foot Break Load: 1,108kg Safe Working Load: 554kg Weight: 218g

Read more less

DO 550 Rope Clutch - Cam Replacement cam for any size Barton Marine DO 550 Rope Clutch.*Sold as an Individual Specifications: Color: Silver Box Dimensions: 1"H x 2"W x 5"L WT: 0.1 lbs UPC: 5035088815463 Brochure (pdf)

Read more less

DO 550 Rope Clutch - Base Plate Replacement base plate for any size Barton Marine DO 550 Rope Clutch.*Sold as an Individual Specifications: Color: Silver Box Dimensions: 1"H x 3"W x 7"L WT: 0.1 lbs UPC: 5035088815470 Brochure (pdf)

Read more less

Quick Cleat - 5/16" - Black The Barton Marine Quick Cleat range is perfect for novices and seasoned mariners and takes the place of tying and releasing knots. Made of nylon reinforced composite and secures braided lines up to 5/16" (10 mm) with a working load limit of 154 lb (70 kg.)  The Barton Marine Quick Cleat offers exceptional value. From securing fenders, gear, painter lines, buckets, boat gears or other gear, the Quick Cleat is designed to alter rope tension in one direction, but grips the rope firmly and securely in the other.Quick Cleats are easy to use.  Simply rotate the lever on top of the cleat, insert the line and release the lever which secures the rope.  Features: Dupont Zytel Construction Easy to install Technical Specifications: Color - Black Material - Zytel nylon Working Load - 154 lb (70 kg) Maximum Rope Diameter - 5/16" (10 mm) Height - 1-1/16" (2.7 cm) Weight - 2 oz (55 g) *Sold as an Individual  Brochure (pdf)

Read more less

DO 550 Rope Clutch - DoubleThe Barton D0 550 clutch is designed for cruising and racing yachts. Manufactured from modern lightweight materials to withstand the harsh marine environment. Molded parts are from high-grade plastics that are strong, light, and impact-resistant. Cams and bases are manufactured from marine grade 'Spectro' anodized aluminum, for high wear resistance and long life. Stainless steel rope fairleads are fitted to both line entry and exit points, this feature prevents wear to both clutch and lines.The true clutch mechanism allows the line to be adjusted through the unit in the closed, locked position with minimal slippage. Released under load is positive and requires little effort. The mechanisms opening and closing action is precise and easy to operate, even with cold, wet hands.  A unique feature of this design is the removable insert on the top face of the handle. Pop this out and you can easily replace it with printed colored inserts to denote at a glance the function of the unit (i.e. main, genoa, spinnaker, etc).The D0 550 clutch features the advantage of a bolt-together construction which allows for ease of servicing and replacement of parts.Features: Modern high-performance materials  True clutch mechanism  Protects lines Maintenance friendly Ergonomically designed Technical Specifications: Dimension (L x W x H)  - 5 ¼” x 2 ½” x 2 ½” (13.3 x  6.3 x 6.3 cm) Hole centres = 3 1/8” (79mm) Maximum Rope Capacity - .47” (1.2 cm) Maximum Holding Power – 1,212 Lb (550 kg) Weight - 1.2 lb (544 g) *Sold as an Individual  Specifications: Color: Black Box Dimensions: 3"H x 3"W x 6"L WT: 1.2 lbs UPC: 5035088815012 Quick Guide (pdf)Brochure (pdf)

Read more less

Small Wincher PairThe Barton Wincher is a specially designed rubber molding that converts your standard winch into a self-tailing winch.  This tried and tested design has been a firm favorite with Sailors for many years.The Wincher works by gripping the rope when the drum is fully loaded and under tension, peeling off the line from the underside of the Wincher as you winch to give a true self-tailing motion.Cleating is achieved by locking the sheet into the Wincher’s ribbed central groove.Technical Specifications: Fits Drum Diameter - 2.5" to 2.75" (64 to 70 mm) Maximum Rope Diameter - .31" to .39" (8 to 10 mm) Weight - 7.13 oz (202 g)  *Sold as a Pair Brochure (pdf)

Read more less

58mm Diameter Ball Bearing Rope Sheave A replacement all-purpose rope sheave. Used throughout the complete Barton block range.  Molded from UV-resistant acetal resin, the Barton sheave is made to survive the harsh marine environment. The unique, super-low friction ball race system features Delrin balls running on a large diameter center boss, which ensures an extremely low friction performance.  Technical Specifications: Overall Diameter - 2- 3/10" (58mm) Hub Width -  .71" (18mm) Bore - .24" (6mm) *Sold as an Individual

Read more less

Kevlar Cam Cleat MaxiManufactured from a composite Kevlar/Zytal material. This advanced material offers performance advantages over carbon fiber and conventional glass-reinforced resins; 'K' cams are solid, lightweight, and have excellent wear resistance. A progressive tooth design ensures maximum holding power on all types of lines, while maintaining minimum wear to both cam and line.Specifications: Max Line Ø: 10mm - 14mm(0.4" - 0.55") FasteningsØ: 5mm (0.20") Fastenings Center: 50mm (1.97") Holding Power: 260kg (573.20lbs) Weight: 50kg (110.23lbs) Specifications: Color: Black Box Dimensions: 1"H x 3"W x 4"L WT: 0.3 lbs UPC: 5035088703005

Read more less
