Round Pad Eye - 57mm Diameter (2-1/4") - FixedThis fixed rounded pad-eye completes the range of fixed pad eyes and thus it can suit any user scenario. For example, it can be used for reefing blocks and fastening points on bowsprits and blocks. Made from duplex stainless steel, it offers excellent mechanical strength for its corrosion resistance. For M6 screws.Applications:  Reefing blocks Fastening points on the bowsprit Blocks fastening Specifications: Materials: Duplex stainless steel grade Weight: (lb) 0.331 / (g) 150 W.L 1 (90 degrees): (lb) 5070.6 / (kg) 2300  W.L 2 (45 degrees): (lb) 4519.4 / kg 2050  W.L 3 (0 degrees): (lb) 4299 / kg 1950 B.L 1 (90 degrees): (lb) 10031 / kg 4550  B.L 2 (45 degrees): (lb) 9038.9 / kg 4100  B.L 3 (0 degrees): (lb) 8598 / kg 3900  Dimensions: A: (inch) 2 1/4" / (mm) 57 B: (inch) 1 1/16" / (mm) 27 D: (inch) 1 3/16" / (mm) 30 E: (inch) 3/4" / (mm) 19  F: (inch) 55/64" / (mm) 22 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Opening Luff Rope PrefeederFeatures: Single handed operation by pushing on the spring Easy to install with a lashing or fixed to the forestay Can be installed below any headsail foil or headsail reefing configuration Stainless steel forged part Applications: Ideal for bowman operations No need to remove the headsail from the luff grove Enables you to save time during operations Smooth and easy sail hoist Specifications: Materials: 316 stainless steel grade Weight: (lb) 0.11 /(g) 50 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 Specifications: Color: Stainless Box Dimensions: 1"H x 2"W x 2"L WT: 0.1 lbs UPC: 358779007486 Quick Guide (pdf)

Read more less

HR Long D Shackle - 10mm Diameter - 25/64"Features: Forged long shackle in HR stainless steel grade (17,4 PH) Outstanding working and breaking load An HR shackle can be up to 60% more resistant than a shackle in 316L stainless steel WLL: only for industrial applications (lifting i.e…) CE marking Applications: Applications requesting high loads Standard applications of the shackle Attachment applications: blocks, head … Do not use it for mooring applications Specifications: Materials: HR 17.4 PH stainless steel grade Working load: (lb) 5820 / (kg) 2640  WLL: (lb) 2640 / (kg) 1200  Breaking load: (lb) 13220 / (kg) 6000  Weight: (lb) 0.362 / (g) 164  Dimensions: A: (inch) 3 5/64" / (mm) 78  B: (inch) 25/32" / (mm) 20  D diameter: (inch) 25/64" / (mm) 10  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 High Resistance (HR) *Sold as an Individual Quick Guide (pdf)

Read more less

HR Bow Shackle - 8mm Pin Diameter Features: Forged bow shackle in HR stainless steel grade (17,4 PH) Outstanding working and breaking load A HR shackle can be up to 60% more resistant than a shackle in 316L stainless steel WLL: only for industrial applications (lifting i.e…) CE marking Applications: Applications requesting high loads To be used when ample room is required Possibility to attach several lines or cables Do not use for mooring applications Specifications: Materials: HR 17.4 PH stainless steel grade Working load: (lb) 3880 / (kg) 1760  WLL: (lb) 1800 / (kg) 820  Breaking load: (lb) 9030 / (kg) 4100  Weight: (lb) 0.15 / (g) 68  Dimensions: A: (inch) 1 29/64" / (mm) 37  B: (inch) 5/8" / (mm) 16  C: (inch) 5/16" / (mm) 8  D: (inch) 5/8" / (mm) 16  D diameter: (inch) 25/64" / (mm) 10  E: (inch) 9/32" / (mm) 7  M: (inch) 1 21/32" / (mm) 42  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 High Resistance (HR) *Sold as an Individual Quick Guide (pdf)

Read more less

Black Watertight U-Bolt - 8mm Diameter - 5/16" - 100mm Length - 3-15/16"Features:  Fully drop-forged product with high-quality stainless steel Outstanding working and breaking loads Complete water-tightness thanks to the resistant rubber collar (black color) Easy installation (no need to use a waterproof sealant) Delivered with bolts and counter-plate Max tightening torque: 18 nm Applications:Various fastening applications: shrouds, lifelines, blocks…Specifications:  Materials: 316L stainless steel grade Color: Black Working load: (lb) 5290 / (kg) 2400  Breaking load: (lb) 10580 / (kg) 4800  Weight: (lb) 0.3 / (g) 136  Dimensions: Length: (inch) 3 15/16" / (mm) 100  A: (inch) 1 27/64" / (mm) 36  B; (inch) 63/64" / (mm) 25  C: (inch) 2 23/64" / (mm) 60  D diameter: (inch) 5/16" / (mm) 8  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

8mm Eye Nut - 21/32" DiameterFeatures: A complete range of single-piece forged products for fastenings applications Outstanding breaking loads Available in different sizes  Applications: Various fastening applications Towing application Waterskiing lines attachment Specifications: Materials: 316L stainless steel grade Breaking load: (lb) 6610 / (kg) 3000 Weight: (lb) 0.112 / (g) 51  Dimensions: A: (inch) M8 x125 / (mm) M8 x125  B: (inch) 43/64" / (mm) 17  C: (inch) 1 27/64" / (mm) 36  D: (inch) 5/16" / (mm) 8  E: (inch) 55/64" / (mm) 22  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Self-Locking Allen Head Pin D Shackle - 6mm Diameter - 1/4"Features: Self-locking shackle with allen head pin D forged in grade 316L stainless steel The pin is locked into one of the indentations The head of the pin does not stick out from the shackle body and thus eliminates any risk of snagging No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking Applications: Ideal to link chains and anchor On the halyard, avoids damaging the sails To be used when the clutter is reduced  Specifications: Materials: 316 stainless steel grade  Working load: (lb) 1320 / (kg) 600  WLL: (lb) 700 / (kg) 320  Breaking load: (lb) 3520 / (kg) 1600  Weight: (lb) 0.049 / (g) 22  Dimensions: A: (inch) 3/4" / (mm) 19  B: (inch) 15/32" / (mm) 12  C: (inch) 15/64" / (mm) 6  D: (inch) 15/32" / (mm) 12  D diameter: (inch) 15/64" / (mm) 6  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load.WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

1/4" Folding Pad Eye - Diameter 1/4"Features: Perfect solution for fastening applications (stay, blocks, jib tack point, lifeline, tether, etc...) Fully drop-forged product with outstanding working and breaking loads regardless of the angle of the load Modern and optimized design to suit the aesthetics of modern boats They can be folded down to minimize the risk of injuries The silicon pad eliminates noise and unpleasant vibrations Modern design Applications:For any fastening/attachment application: shroud, stay, blocks, lifeline, jib tack point, etc…)Specifications: Materials 17.4 pH stainless steel/316L stainless steel grade Working load (lb) 2510 Breaking load (lb) 6610 Weight (lb) 0.172 A (inch) 1 49/64" B (inch) 1 1/16" C (inch) 19/32" D (inch) 1 47/64" d diameter (inch) 15/64" D diameter (inch) 15/64" E (inch) 1 39/64" F (inch) 1 1/16"

Read more less

Webbing Snap Hook - 30mm - Length 60mmFeatures: Grade 316L forged webbing snap hook Various applications onboard Outstanding working and breaking loads Modern design Applications:Various uses onboard: canopy installation fastening applications…Specifications: Materials 316L stainless steel grade Length (inch) 2-23/64" Working load (lb) 440 Breaking load (lb) 660 Weight (lb) 0.077 Dimensions (see 2nd image): A (inch) 5/16" B (inch) 1-3/16"

Read more less

Self-Locking Long D Shackle - Diameter 5mm - 3/16"Features: Self-locking long shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications CE Marking and batch number Applications: Standard applications of shackle requiring more length Attachment applications: blocks, head... Specifications: Materials 316 stainless steel grade Working load (lb) 880 WLL (lb) 440 Breaking load (lb) 2200 Weight (lb) 0.037 Dimensions (see 2nd image): A (inch) 1-9/64" B (inch) 25/64" C (inch) 13/64" D (inch) 25/64" D diameter (inch) 13/64" E (inch) 5/32" F (inch) 1-39/64" G (inch) 1-1/32"

Read more less

3" HR Safety Snap Hook - 75mmFeatures: HR 17.4 PH stainless steel grade forged snap hook Various applications onboard Outstanding working and breaking loads Modern design Applications:Various uses onboard: fastening applications

Read more less

Self-Locking D Shackle - Diameter 6mm - 1/4"Features: Self-locking D shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications (lifting i.e…) CE marking and batch number Applications: Standard applications of the shackle Attachment applications: blocks, head… Specifications: Materials 316 stainless steel grade Working load (lb) 1320 WLL (lb) 700 Breaking load (lb) 3520 Weight (lb) 0.049 Dimensions (see 2nd image): A (inch) 25/32" B (inch) 15/32" C (inch) 15/64" D (inch) 15/32" D diameter (inch) 15/64" E (inch) 13/64" F (inch) 1-11/32" G (inch) 1-7/32"

Read more less
